Wine Guardian | 5500BTU/h Ducted Compressor

Versatile Ducted Cooling with the Wine Guardian D050

The Wine Guardian D050 is a self-contained, fully ducted cooling system designed to maintain stable conditions in medium-sized residential or commercial wine cellars.

WHY CHOOSE THE WINE GUARDIAN D050 WINE CELLAR COOLING UNIT?

• Self-contained, fully ducted wine cellar cooling system
• Suitable for medium-sized residential and commercial wine cellars
• Maximum cooling capacity of 6,320 BTU/h
• Indicative room-volume range from 650 to 3,000 cubic feet depending on the project’s heat load
• May also suit smaller wine cellars containing a significant amount of glass
• Installs outside the cellar to keep mechanical equipment out of view
• Evaporator, fans, compressor, condenser and controls housed within a single unit
• Requires no refrigerant lines between separate indoor and outdoor sections
• Maintains standard wine-storage temperatures around 55°F to 58°F
• Precise digital electronic controls
• Published temperature accuracy of ±1°F
• Rated evaporator airflow of up to 390 CFM
• Approximately 320 CFM of airflow at 0.20 inches of static pressure
• Internal insulation helping reduce temperature loss and condensation
• Coated evaporator coil supporting long-term durability
• Multi-panel construction providing convenient installation and component access
• Designed to be serviced and repaired in the field
• Compatible with Wine Guardian remote controllers and sensors
• Supports up to three additional remote sensors for more accurate measurements
• Compatible with optional integrated or freestanding humidifiers
• Optional humidification can help maintain relative humidity from 55% to 65%
• Optional All Wine Temperatures Bundle extends the range from 45°F to 64°F
• Optional Extreme Climate Protection Bundle for particularly hot or cold environments
• Also available in a water-cooled configuration
• 115 V, single-phase and 60 Hz electrical supply
• Rated cooling-mode current draw of 11.3 A
• Uses R134a refrigerant
• Recommended minimum ductwork diameter of 12 inches
• ½-inch condensate drain connection
• Dimensions: 41.5" L x 22.5" W x 19" H
• Weight: 125 lb
• Contractor installation recommended
• Standard warranty covering parts for 2 years and labour for 1 year

The Wine Guardian D050 wine cellar cooling unit combines all principal components within a single ducted system installed outside the storage space. Its maximum capacity of 6,320 BTU/h makes it suitable for medium-sized residential or commercial cellars, as well as certain smaller projects containing extensive glass. Digital controls, internal insulation and accessible multi-panel construction support stable performance and convenient servicing. Available options for humidification, heating and extreme-climate protection allow this ducted wine cellar cooling system to be adapted to the specific requirements of each project.
